Post-hung steering - The ultimate expression of compact and flexibility

The turning radius is only 2600mm, falling between mid-hung and short-hung types, achieving a balance between flexibility and stability.

The wheelbase is only 1580mm, the shortest in the entire series, and the steering response is extremely fast.

The total length of the vehicle is only 3600mm, and the width is only 1800mm. This is the narrowest and most compact model in the entire series.

The rear hinge point design allows for a larger steering angle of the front frame, and the rear wheels have excellent followability.

Four-wheel drive - All-terrain passing capability

The four-wheel drive system can adapt to all scenarios including muddy terrain, snowy terrain, sandy terrain, and rocky slopes.

Wheel-mounted heavy-duty cast steel bridge, resistant to impact and capable of withstanding heavy loads. Even in harsh conditions, it remains reliable.

The maximum climbing angle is ≤ 38°, and there is no pressure when operating on steep slopes.

Stable lifting - the heavy-load capacity is not reduced.

Rated lifting weight: 3500kg, consistent with the larger models.

The lifting height can be selected from 3000 to 6000mm, meeting the needs of most stacking and loading/unloading operations.

The width of the frame is 160mm, and it is structurally compact yet maintains high strength.

Off-road chassis configuration

20.5/70-16 reinforced tires, with large tread design, providing excellent grip

The front end of the gantry has a ground clearance of 180-250mm, enabling it to pass through obstacles smoothly and effortlessly.

Efficient power system

490 Euro IV variable-frequency engine, meeting Euro IV emission standards, energy-saving and environmentally friendly

265 dual high-low speed torque converter transmission, capable of flexible switching between high and low speeds. It offers strong climbing power at low speeds and efficient transfer performance at high speeds.

Lightweight advantage - Lightest in the entire series

Overall weight: 4350kg (standard version) / 3280kg (lightweight version)

The entire series is the lightest, exerting less pressure on soft surfaces (farmland, sandy ground, snowy ground), thereby reducing ground compaction.

The lightweight design not only reduces fuel consumption but also lowers the usage cost.
