Core performance

Rated lifting capacity: 3500kg

Stable for carrying heavy goods and capable of meeting the majority of medium-sized handling requirements.

Adjustable lifting height: 3000 – 6000mm

Suitable for various loading and unloading scenarios, optional upgrades are available to flexibly handle operations such as high-level stacking and truck loading/unloading.

Maximum climbing angle: ≤ 38°

Easily handle steep slopes, muddy ground, and gravel ramps. Its climbing capability far exceeds that of ordinary forklifts.

All-terrain passability

All-time four-wheel drive

Maintains four-wheel power output under any road conditions, ensuring excellent traction and stability on slippery, soft or uneven surfaces.

Wheel-mounted heavy-duty cast steel axle

High-strength heavy-duty vehicle axle, with strong impact resistance and significantly improved durability, suitable for extreme working conditions.

Enhanced tires: 20.5/70-16

With large pattern and wide tread design, they perform equally well in muddy, snowy and sandy conditions as on flat ground.

Front end clearance of the frame: 170–250mm

Effectively prevents chassis from being damaged, enabling smoother crossing of obstacles.

Compact and flexible

The turning radius is only 2900mm, allowing it to maneuver freely even in narrow construction sites, forest paths, or mountainous orchards.

Power and Transmission

490 Euro IV Variable Frequency Engine

Complies with Euro IV emission standards, is energy-efficient and environmentally friendly, and also provides abundant low-speed torque. Optimized for off-road conditions.

265 Dual High and Low Speed Torque Converter Transmission

Flexible switching between high and low speeds, balancing the explosive power for low-speed climbing and the efficiency for high-speed shifting.

Structural durability

Overall dimensions: 4000×1800×2730mm

Wide-body frame design, providing a wide field of vision and greater stability.

Wheelbase: 2080mm

The extended wheelbase enhances the stability during heavy-load driving and reduces the body sway on bumpy roads.

Overall machine weight: 4550kg (standard version) / 3360kg (lightweight version)

The self-weight is reasonable and the adhesion is strong. It can be flexibly selected according to the application scenario.

Applicable scenarios

Mountainous orchards, nurseries, woodlots

Construction site, muddy foundation, demolition site

Farm, livestock farm, feed warehouse

Snowy terrain, sandy beaches, transportation of mining materials

Emergency rescue and field logistics

Customizable upgrade

This product supports targeted upgrades and can be customized according to user requirements:

Different lifting heights (3000 - 6000mm options available)

Enclosed cab (air conditioning/heating)

Various tools (side displacement forks, distance adjustment forks, rotation forks, etc.)

Special tires (snow tires, solid tires, etc.)
