Core Performance

Rated lifting capacity: 3500 kg

Stably supports heavy loads, meeting the majority of medium-duty material handling needs.

Adjustable lifting height: 3000–6000 mm

Adapts to various loading and unloading scenarios, with optional upgrades for flexible use in warehouses, trucks, or high-stack operations.

Maximum climbing angle: ≤38°

Easily handles steep slopes, muddy terrain, and gravel paths, with climbing capability far exceeding that of conventional forklifts.

All-terrain capability

Four-wheel drive: Full-time four-wheel drive system ensures traction and stability on slippery, soft, or uneven terrain.

Wheel-end heavy-duty cast steel axle: High-strength axle with excellent impact resistance, suitable for heavy loads and harsh road conditions.

Reinforced Tire: 20.5/70-16

Large tread pattern and wide tread design provide excellent traction on mud, snow, and sand, offering smooth performance on any terrain.

Front clearance: 180–250 mm

Effectively prevents underbody damage and offers superior ground clearance.

Compact and agile

With a turning radius of just 2,900 mm, it moves freely even in tight construction sites or narrow forest trails.

Power and Transmission

490 Euro IV Variable Frequency Engine

Complies with Euro IV emission standards, energy-efficient and environmentally friendly, while delivering ample low-speed torque, ideal for off-road conditions.

265 Dual-Range High-Low Torque Converter Transmission

Flexible high-low range shifting, combining strong low-speed climbing power with efficient high-speed travel.

Structural Durability

Overall dimensions: 3800 × 1850 × 2150 mm

Compact design ensures both stability and maneuverability.

Overall weight: 4,500 kg (standard) / 3,320 kg (lightweight version)

Optional based on application scenarios, with reasonable self-weight and strong traction.

Customizable Upgrades

Supports targeted configuration upgrades based on user requirements, such as mast height, attachment types, and cab enclosure.
