ATWY4-150-1-B Single-Mast Aluminum Alloy Lifting Platform: A Lightweight, Flexible Solution for 4m Low-Altitude Operations

Single-Mast Lightweight Design: Precise Adaptation to Small-Space Operations

The ATWY4-150-1-B features a single-mast structure crafted from high-strength, high-quality aluminum alloy profiles. With a maximum working height of 4m and a compact 0.65m×0.65m platform, it boasts a 150kg rated load capacity, ideal for single-person operations with small tools (such as electric screwdrivers or testing instruments) in low-altitude tasks.

Weighing only 280kg with overall dimensions of 1.42m×0.78m×1.97m, it navigates narrow spaces (e.g., elevator shafts, equipment gaps) with ease. A single person can effortlessly pull or move it, solving the "bulky and hard to maneuver" issue of traditional aerial equipment.

The platform surface undergoes anodization for wear and corrosion resistance. Its bottom polyurethane tires reduce walking resistance, minimize noise (≤60dB), and avoid damaging delicate floors like epoxy or marble—perfect for environments with strict floor protection requirements, such as hospitals, laboratories, and shopping malls.

Core Performance & Intelligent Control: Dual Assurance of Efficiency and Safety

Power & Endurance: A 1.1kW motor adapts to 220V power supply, offering a stable lifting speed of 0.5m/s. With a motor temperature rise ≤40℃ after 8 hours of continuous operation, it meets daily high-frequency usage needs. Optional configurations include battery-powered lifting (DC supply) or AC/DC dual-use models, eliminating cable constraints for temporary outdoor operations.

Convenient Control: Equipped with a standard remote controller, it allows lifting operations within a 10m range—no need to bend down or climb to press buttons. The platform features a quick locker for one-touch height locking, with positioning accuracy of ±10mm, suitable for precision tasks like lamp installation or pipe maintenance.

Safety Protection: Integrates multiple protective devices—a level gauge monitors tilt angles in real time (triggering alarms when >3°), an emergency descent valve ensures manual rapid lowering during power outages, and a closed anti-fall space formed by lifting guardrails and chain protection. Hidden outriggers expand the support area by 30% when deployed, enhancing operational stability.

Configuration Upgrades & Scenario Adaptation: From Small Spaces to Diverse Environments

Standard Configuration: Lifting guardrails, quick locker, remote controller, emergency descent valve, polyurethane tires, level gauge, hidden outriggers—meeting basic safety and convenience needs.

Optional Upgrades: Explosion-proof motor and electrical components for flammable and explosive areas (e.g., chemical workshops); auxiliary walking function reduces physical effort for long-distance relocation; hand pump as emergency power backup for sudden power outages.

Key Application Scenarios:

Indoor precision operations: Office ceiling repairs, laboratory equipment installation, shopping mall display setup (navigates narrow passages easily);

Light outdoor operations: Street lamp base maintenance, billboard replacement (battery-powered models work without mains electricity);

Industrial auxiliary scenarios: Production line equipment inspection, warehouse shelf picking (lightweight design avoids floor damage).
