ATWY8-130-1 Aluminum Alloy Lifting Platform: A Single-Mast Flexible Adaptation Solution for 8m Mid-High Altitude Operations

8m Height Coverage: Precise Reach for Mid-High Altitude Operations

Compared to 4-6m platforms, the maximum working height of 8m achieves an upgrade from "reachable" to "full coverage": it can not only meet the needs of restocking 8m-high shelves in logistics warehouses and organizing top-level cargo positions in e-commerce sorting centers but also handle 8m-high lamp replacement in stadiums and 8m-high pipeline maintenance in factories—expanding mid-high altitude scenarios by 40% compared to 6m platforms.

The 0.65×0.65m platform retains operational space while its edges are treated with anti-slip raised patterns (1.5mm in pattern height). Combined with 1.1m-high lifting guardrails and chain protection, the standing stability of a single person carrying tools (such as electric wrenches and testing instruments) at 8m height is improved by 20%. The bottom of the platform is pre-equipped with 4 tool hook holes, which can fix cable reels and parts boxes weighing less than 10kg to prevent tools from falling at high altitudes.

130kg Load Balance: Efficient Adaptation for Light-Load Scenarios

The 130kg rated load precisely matches the needs of "one person + standard tool set"—for example, carrying a 10kg impact drill + a 5kg level + a 5kg spare parts bag (total weight approximately 120kg). This not only avoids overload risks but also reduces unnecessary energy consumption compared to 150kg-class platforms (motor efficiency increases by 12% at 130kg load at the same height).

The 380kg overall weight is optimized through a "gradient wall thickness design for masts": the main mast of the single-mast model has a wall thickness of 3.5mm (4mm at key parts), and each mast of the dual-mast model is 3mm thick. While ensuring structural strength at 8m height, it is 15% lighter than 4-mast heavy-duty platforms of the same height. A single person can easily turn it on concrete floors (with a turning radius of 1.6m), solving the pain point that "high-altitude equipment must be bulky".

8m Height-Exclusive Safety Design: Full-Link Protection from Prevention to Emergency

Enhanced High-Altitude Stability: The level gauge adopts dual-axis monitoring (sampling frequency 15Hz). At 8m height, if the tilt exceeds 2.5°, it triggers sound-light alarms and lifting lock (0.3° stricter than 6m-class platforms) to prevent high-altitude rollover. When deployed, the hidden outriggers have a support area of 1.8×1.6m (single-mast model), with ground pressure ≤0.2MPa, avoiding indentation on epoxy floors or wooden floors.

Stable Lifting Control: The 1.1kW motor optimizes hydraulic flow for 8m height, with a lifting speed of 0.35m/s (taking about 23 seconds to rise from the ground to 8m). The platform vibration amplitude during start and stop is ≤3mm, preventing precision tools (such as laser line projectors) from being affected by shaking and ensuring measurement accuracy.

Dual Emergency Protection: The emergency descent valve is equipped with a "graded speed regulation" function—when power is cut off at 8m height, the descent speed can be controlled via a knob (0.2-0.4m/s). Combined with a manual pump backup system (which can lower to the ground in 30 seconds), it eliminates the risk of high-altitude detention.

Power and Mobility: Efficient Support for 8m Operations

Power Adaptation: 220V mains power supply is compatible with optional 110V wide-range input, operating stably even in workshop environments with ±10% voltage fluctuations. After 8 hours of continuous lifting operations (once every 15 minutes), the motor temperature rise is ≤40℃, and the body surface temperature is ≤45℃, making it suitable for operations in enclosed factories in summer.

Mobility Details: Polyurethane tires adopt a "wide tread + silent formula" (70mm tread width) with walking noise ≤55dB, avoiding disturbance when moving in quiet environments such as hospital outpatient buildings and school libraries. The tire edges are treated for wear resistance, showing no obvious wear after 5,000 meters of cumulative walking on concrete or floor tiles.

Configuration Expansion: Scenario Compatibility with On-Demand Upgrades

Core Advantages of the Basic Version: Remote controller (10m anti-interference), polyurethane tires, and a full set of safety devices meet regular 8m high-altitude operations (such as warehouse restocking and venue maintenance).

Scenario-Adapted Upgraded Versions:

Battery-powered lifting version (12V/90Ah): 6-hour battery life, suitable for outdoor 8m-high surveillance pole installation and community street lamp maintenance, with a full charge achievable in 4 hours;

Explosion-proof motor version (Ex dⅡBT4): The entire machine is anti-static, suitable for 8m-high pipeline inspection in chemical workshops, preventing sparks from igniting volatile gases;

Auxiliary walking version: Equipped with electric drive wheels (2.5km/h speed), reducing manpower by 70% during relocation in 8m shelf areas of large logistics parks.

Key Application Scenarios: Exclusive Value at 8m Height

Efficient Logistics and Warehousing Operations: The single-mast model passes through 0.9m-wide shelf aisles, completing top-level cargo restocking at 8m height. With a 130kg load, it can carry 4 standard cartons at a time, reducing the number of up-and-down trips;

Cultural and Sports Venue Maintenance: The dual-mast model operates in open areas of stadiums, replacing chandeliers at 8m height. Remote control eliminates the hassle of setting up scaffolding;

Industrial Factory Inspection: The three-mast model stably carries testing instruments at the top of 8m-high production lines, completing fault detection of suspended conveyors;

Municipal Facility Installation: The four-mast model is used in the construction of 8m-high bus stop canopies. Multiple masts support against mild outdoor winds, with platform shaking ≤5mm.

Product Positioning: A "Flexible All-Rounder" for 8m Mid-High Altitude Operations

Centered on "8m height + optional multi-mast design + 130kg precise load capacity", the ATWY8-130-1 not only solves the "unreachable" problem of 4-6m platforms but also avoids the "bulky and hard to move" drawback of platforms over 10m. Through customized mast quantity, upgraded safety details, and scenario-based configurations, it transforms 8m mid-high altitude operations from "relying on large equipment" to "being completed easily and efficiently", becoming an exclusive solution for logistics, industry, culture, sports, and other fields.
